2-½ years in development with every detail carefully considered and meticulously executed, the TOA is the culmination of all the CHAPTER2 frames that have come before it. TOA which means "to be victorious, win" in Maori delivers an all-out, no-compromise carbon fibre race-ready frame platform designed, engineered, and manufactured to the most exacting standards.

Inspired by the TERE’s Performance All-Road DNA and the AO’s versatility, the TOA has all its cables/hoses tucked away from sight and the wind, creating an aerodynamically seamless transition between the MANA Bar and the TOA’s Kamm-Tail chassis.

Sporting a T47 Bottom Bracket for easy maintenance, the aluminium BB Shell works in unison with the high-tensile carbon carefully laid into the BB area to increase stiffness by up to 7.3% over the TERE. Additionally, the use of a Latex mandrel for the whole front triangle has increased the Headtube stiffness by 23.5% over the TERE for that out of the saddle and power to the pedals moment.

Other enhancements such as the bundled MANA Bar, Quick-Fit headset spacers, up to 32mm of tire clearance, vibration dampening Seatstays and Seatpost makes for a package that ticks all the right boxes



FEATURES/BENEFITS

  • Stiff Racing Frame: Improved Power Transfer & Precise Steering
  • Cable Integration: Improved Aerodynamics & Clean Aesthetics
  • Compact Kamm-Tail: Aerodynamic & Stiffness where Needed
  • Up to 32mm Tire Clearance: Increased Tire Options
  • Dropped Stays: Improved Compliance for Endurance Rides
  • T47 BB: Noise-free & Easy to Service
  • Disc Brakes Only: Improved Braking & Modulation
  • Frameset Only: Bespoke & Personal
  • Limited Edition: Exclusivity



Specifications

FRAME: Chapter2 TOA Carbon: 100% Made in Japan by Toray
FORK: Chapter2 Carbon: 100% Made in Japan by Toray
HANDLEBAR/STEM: Chapter2 MANA2 Integrated
TAPE: Chapter2 Black Bar Tape
SADDLE: Fizik Fizik Vento Argo R5 Saddle
SEATPOST: Chapter2 Carbon seat post 15mm offset
FRONT BRAKE: Shimano 105 Di2
REAR BRAKE: Shimano 105 Di2
SHIFT LEVERS: Shimano 105 Di2
FRONT DERAILLEUR: Shimano 105 Di2
REAR DERAILLEUR: Shimano 105 Di2, 12-speed
CHAIN: Shimano 105
CASSETTE: Shimano 105 11-30
CRANKSET: Shimano 105 50/34
BOTTOM BRACKET: Wheels Manufacturing T47
FRONT WHEEL: Fulcrum 5 Disc Wheel
REAR WHEEL: Fulcrum 5 Disc Wheel
TYRES: Goodyear Eagle F1 - 700x28c
INNER TUBES: Presta, 60mm valve



The following items are interchangeable and can be tailored to your size preferences: crank length, handlebar size, chainring size, cassette, saddle, tyres.

The MANA2 carbon handlebar is available in 11 size combinations so that you can dial in your desired position with effective stem lengths from 80-130mm and widths from 380-435mm. Learn more
